STAR ST-3600 — All-in-One IP & HD CCTV Tester

₹35,000.00

The STAR ST-3600 is a compact, Android-based 5.4″ IPS CCTV tester designed for CCTV technicians, security system integrators, and network engineers. Built to handle 4K IP camera testing, 8MP HD-Coax (TVI/CVI/AHD) support, PoE & DC outputs, and RJ45 TDR cable fault location, this all-in-one device ensures faster CCTV installation, troubleshooting, and on-site reporting.

Whether you’re installing a small office CCTV setup or a large-scale surveillance network for Indian commercial complexes, housing societies, or factories, the ST-3600 gives you batch camera activation, test report generation, and live screen sharing to mobile/PC — cutting installation time and reducing repeat visits.

Category: Brand:

Description

Rugged, Portable CCTV & Network Testing Tool for IP, HD-Coax & Analog Camera Installations

Handheld CCTV & Network Tester with 4K IP playback, 8MP HD-Coax/Analog support, built-in PoE (48V/25.5W), and RJ45 TDR cable testing — perfect for quick CCTV camera setup, PTZ control, cable certification, and network troubleshooting in Indian security installations.

Key Features for Indian Installers

  1. Display & Video Testing
    • 5.4″ IPS Touchscreen (1920×1152 resolution) for sharp image previews even in sunlight.
    • 4K IP camera playback (H.265 / H.264) with RTSP & ONVIF support.
    • HDMI input (4K@30fps) & VGA input (2048×1152@60fps) to test DVR/NVR output.
  2. Camera Compatibility & PTZ Control
    • Works with IP, CVBS, TVI, CVI, AHD — up to 8MP/4K resolution.
    • Auto-detect HD-Coax formats for faster setup.
    • PTZ control via coax or RS485 — supports Pelco-D/P, Hikvision, Dahua, and other protocols.
    • Batch activation for Hikvision/Dahua — saves hours on multi-camera jobs.
  3. Power & Connectivity for Indian Sites
    • Built-in PoE Output (48V, 25.5W) to power IP cameras directly — no extra injector needed.
    • DC 12V/3A output for analog cameras.
    • Wi-Fi hotspot creation for mobile access, USB & SD card storage, Android app support.
  4. Network & Cable Testing
    • RJ45 TDR Cable Tester — measures length, attenuation, impedance, skew, and locates faults (up to ~180m).
    • Network tools: IP scan, ping, traceroute, DHCP server, port flash, traffic monitor.
    • Cable certification to ensure zero downtime after handover.
  5. Reporting & Utilities
    • Generates camera & cable test reports — ideal for tender submissions and client handovers.
    • Tester Play: live screen mirroring to Android phones or PCs — helpful for training junior staff on-site.
    • Snapshot, video record, audio test, voltage/power display.
  6. Physical & Power Specs
    • Weight: ~0.8 kg; Size: 183×110×36.5 mm — lightweight for long field jobs.
    • Battery: 7.4V / 3350 mAh — 5 hours runtime, 3–4 hours fast charge.
    • Operating temp: −10°C to +50°C — ready for India’s heat and monsoon conditions.

Why Indian Technicians Choose the ST-3600

✅ One device replaces 7–8 tools — no more carrying multiple testers.
✅ Cuts installation time by up to 50% with batch camera activation & PoE power.
✅ Tender-ready reports for professional handover.
✅ Built to handle India’s outdoor climate.

Specifications

LCD Item SeriesCCTV tester
DisplayNew 5.4 inch IPS touch screen, 1920×1152 resolution
Video ModeCVBS1 channel BNC input, NTSC/PAL (Auto adapt)
PTZ control, RS485 control, Baud 600-115200bps, compatible with more than 30
protocols such as PELCO-D/P, Samsung, Panasonic etc.
IP camera test
4K/H.265/H.264		Rapid VideoAuto view the video, create testing report
HIKVISION test
tool		Support batch activate HIKVISION cameras and modify IP address,
modify password etc. Self-defined modify channel name, can
quickly change H.264 and H.265 video, open wide dynamic mode.
Factory restore, etc.
DAHUA test
tool		Support batch activate DAHUA cameras and modify IP address,
username and password. Self-defined modify channel name.
HD Coaxial test8MP TVI camera test, 3840 x 2160P 12.5/15 FPS, UTC control/ call OSD menu
8MP CVI camera test, 3840 x 2160P 12.5/15 FPS, UTC control / call OSD menu
8MP AHD test, 3840 x 2160P 15FPS, UTC control / call OSD menu
HDMI input1 channel HDMI input, support 4K 30FPS. The resolution as follow: 4K_3840 x
2160/2K_2560 x 1440P/
1920×1080P /1920×1080i /720×480P /720×576P
/1280×720P/1024×768P/1280×1024P /1280×900P /1440×900P, etc
Video ModeVGA input1 channel VGA input, support 2048 x 1152 60FPS. The resolution as follow: 2048 x
1152P/ 1920 x 1200P 60FPS/1920×1080P 60FPS /1792×1344P 60FPS /1680x 1050P
60FPS/ (1600x1200P/900P 60FPS)/1440x900P 60FPS/1360x768P 60FPS/
(1280×1024/960/800/768/720P 60FPS)/1152x870P 60FPS/1024x768P
60FPS/800x600P 60FPS/600x480P 60FPS
Zoom Image4x zoom, to enlarge image, Screen snapshot, record, save, view and record and
play back
Power output12V/3A powerOutput DC12V/3A power out, supply temporarily power for the camera
PoE power
output		48V PoE power output, max power 25.5W
Cable testUTP cable testTest UTP cable connection status and display on the screen. Detect the near-end,
mid-end and far-end fault point of the RJ45 cable plug.
RJ45 TDR
cable test		Test cable pair status, length, attenuation, reflectivity, impedance, skew, can create
test report. Max measurement is 180M.
Tester PlayScreen projection: Tester, mobile phone and PC display at the same time
(For android version mobile phone)
Network testTrace route, Link monitor, DHCP server, port flashing, Ping test
Wi-FiBuilt in WIFI, speeds 150M, display wireless camera image
Audio test1 channel audio signal input, test whether sound normal.
Power
management		Display DC 12V input & output voltage and power in real time
Data monitorCaptures and analyzes the command data from controlling device, also can send hexadecimal
External power
supply		DC 12V 1A
BatteryBuilt-in Lithium-ion battery
RechargeableAfter charging 3-4 hours, normal working time 5 hours
Operation settingOSD menu, select your desired language: English, Chinese, Korean, Russian, Italian, French,
Polish, Spanish, Japanese, Deutsch, Turkish, Portuguese, Czech etc
Auto off1-30 (mins)
Working
Temperature		-10℃—+50℃
Working Humidity30%-90%
Dimension Weight183mm x 110mm x 36.5mm / 0.8kg
