Advanced Underground Cable Fault Locator

MRP:

Introducing the next-generation Star Advanced Underground Cable Locator, designed to redefine the standards of underground cable and pipeline detection. Equipped with Integrated GPS (Optional), this advanced tool delivers unmatched accuracy and functionality, making it the ultimate solution for professionals in utility mapping and fault detection. With its robust design and intuitive interface, the Star Advanced Underground Cable Locator is built to perform under diverse environmental conditions, ensuring reliable results every time.

Category: Tools & Assessories Brand: Star

Description

Introducing the next-generation Advanced Underground Cable Locator, a cutting-edge solution engineered to set new benchmarks in underground cable and pipeline detection. Featuring Integrated GPS technology (Optional), this state-of-the-art device provides unparalleled precision and functionality, making it the go-to tool for professionals in utility mapping, fault detection, and infrastructure maintenance.

Designed for reliability and efficiency, the Star Advanced Underground Cable Locator boasts a rugged construction to withstand challenging environmental conditions while maintaining peak performance. Its user-friendly interface ensures effortless operation, allowing technicians to achieve accurate results with minimal training. Whether you’re navigating complex utility networks or conducting routine inspections, this advanced tool is built to deliver consistent, high-quality outcomes.

The Star Advanced Underground Cable Locator is not just a device—it’s a game-changer for professionals seeking accuracy, durability, and ease of use in their fieldwork.

Features

Here are the features of the Fibershot Cable Locator with Integrated GPS:

Integrated GPS: Precise location tracking of fiber optic cables.
Easy Cable Detection: Accurately locates buried cables in various environments.
Advanced Signal Processing: Minimizes interference for more accurate results.
User-friendly Interface: Simple operation with clear digital displays.
High Sensitivity: Detects cables at long distances and depths.
Durable Build: Designed for rugged field conditions.
Lightweight and Portable: Easy to carry and handle during inspections.
Battery Efficient: Long-lasting battery for extended usage.
Versatile Usage: Ideal for both telecom and utility applications.

Technical Specifications

Receiver

Accuracy	Depth Measurement: ±5% (depth ≤3m), ±10% (depth 3m–20m)
Power Supply	7.4V DC 3400mAh rechargeable Li-ion battery pack
Receiving Frequency	Active (577Hz to 201kHz), Passive (50Hz to 250Hz).
Display	3.5-inch color LCD, high visibility in any lighting conditions.
Connectivity	Bluetooth-enabled (optional) for GIS and data apps.
Receiving Configuration	Built-in receiving coil; Rogowski coil; Stethoscope(Remote Antenna);
Bluetooth (Optional)	Bluetooth communication; Connecting to mobile apps for various data processing;
Locating Mode	Broad Peak Mode, Peak Response Mode, Null Mode
Locating Mode and Screen	Classic Mode; Plan View Mode; Signal Curve Mode;
Depth Measurement Accuracy	±5%（depth below 3m); ±10%（depth from 3m to 20m）
Target Cable Direction Identification	During the cable route locating, the pinpoint arrow points to the target cable under test.
Sound Indication	FM: Sound pitch changes with signal strength
Anti-interference ability	The extremely narrow receiving frequency band can fully suppress power frequency and harmonic interference from adjacent running cables and pipelines.
Cable Identification	Rogowski Coil; Stethoscope (Remote Antenna); Calibration Cable：1～10 Calibration value: The percentage of the received signal and the transmitted signal Successful Identification: 75%~135%; The transmitting clamp, receiving clamp, and loading signal must be in the same direction
LED night lighting	Flashlight installed in the receiver
Dimensions	Approx 290mm(L)×128mm(W)×700mm(H)
Weight	Approx 1.90kg
Charger	DC 8.4V 1A
Flashlight Power	1W max
External Connector	Mini-B USB socket for firmware updates: 1 DC charging port: 1 Flexible coil connection socket: 1
Rogowski Coil	L: approx 620mm Wire Diameter: φ8mm
Coil Diameter	φ200mm, customized
Stethoscope Dimension	L: 111mm×W: 60mm×H: 27mm, optional
Length of Lead Wire	Stethoscope: Approx 3m
Working temperature and humidity	-10℃～40℃；Below 80%Rh
Storage temperature and humidity	-10℃~50℃；≤95％RH, no condensation
Dielectric Strength	AC3700V/rms(Between the upper and lower ends of the housing)
Safety Regulation	IEC61010-1 CAT Ⅲ 600V，IEC61010-031，IEC61326，Pollution level 2

Transmitter/Tx

Function	Multiple frequency signal transmission;
Power Supply	11.1V DC 12800mAh Rechargeable lithium-ion battery pack
Locating Method	Direct Connection; Signal Coupling; Induction;
Output frequency	577Hz，640Hz，1280Hz，2.56kHz，3.20kHz，4.09kHz，8.19kHz，10kHz，33kHz，66kHz， 82kHz，201kHz
Output Power	5W/10W max，10 power gears available
Impedance	Fully automatic real-time impedance matching and protection functions
Output voltage for direct connection	150V max
Circuit protection	Overload and short-circuit protection
LCD	5.6-inch LCD color screen
Weight	Transmitter: approx 3.85kg Transmitting Clamp: approx 1.18kg
Charger	DC 12.6V 2A
Transmitting	Dimension: L:297mm×W194mm×H39mm
Clamp	Diameter:φ150mm Lead wire: 3m Red Test Lead: 3m; Black Test Lead: 3m;
External Connector	Type-B USB socket for firmware updates: 1 DC charging Port: 1 Signal transmitting clamp connection socket: 1 Direct connection test lead interface: 2
Pressure Resistance	The case can withstand weight of approx 200kg
Dielectric Strength	AC 3700V/rms(Between the upper and lower ends of the housing)
EMC	IEC61326(EMC)
Safety Regulation	IEC61010-1(CAT Ⅲ 300V, CAT IV 150V, Pollution Level 2)
